How to SET TIME and PROGRAM CLACK WS1 3 button Valve

How to SET TIME and PROGRAM CLACK WS1 3 button Valve

If you’re looking for a quick and easy video on how to set time and program a Clack WS1 3 button valve you’ve found it here! Whether your valve is on a water softener, iron filter, sediment or automatic back washing carbon filter this video is for you! The Clack WS1 family of water treatment valves comes in different configurations. Today we’re talking about the 3 button or TC which means time clock valve. The biggest difference between these valves from the 4 and 5 button valves is that these are time activated instead of demand activated by your water usage. Although these can be used on a water softener they are best used on back washable filters for Nextsand sediment or Carbon chemical removal like chlorine. This valve has changed slightly over the years, the first versions did not have a power cell backup like this newer version and did not display the minutes when the current time is displayed. I should mention that if you’ve invested in one of these valves on a piece of water filtration equipment from us, it will already be programmed. All you need to do is set the current time, frequency of back wash and regen time, all the other settings have been pre programmed. The rest of the information today is for getting into the programming to make more significant changes or for new applications or retro fitting valves onto your tank. I should also mention that if you ever want a basic manual for one of these valves, just remove the face plate and if it’s an older valve, you’ll find it there. If it’s a newer valve just use you QR scanner to get to the manual. Let’s get started: To Set Time of Day 1. Press “SET HOUR”. Adjust hours with up or down arrow. 3. Press “NEXT”. Adjust minutes with up or down arrow. 5. Press “NEXT” to complete and return to normal operation. To Set Time of Regeneration 1. Press the SET HOUR and up arrow buttons simultaneously for 3 seconds. 2. Using the up or down buttons set the Hour 3. Press "NEXT". Do not change days override from 14. 3. Press “NEXT”. Using the up or down buttons set the Regeneration Time similar to setting the current time above. 4. Press “NEXT” returning to normal operation. To Change Programming 1. Press “SET HOUR” and “UP” simultaneously for 3 seconds and release then again Press “SET HOUR” and “UP” simultaneously for 3 seconds and release. 2. Choose the desired programming by pressing the UP or DOWN button 3. If program P0 to P6 was selected, you will need to enter the minutes fill time. If program P7 to P9 was selected Press SET HOUR to go to minutes of fill. Note: For each minute of fill 0.5 gallons of water is added to the solution tank. With salt (sodium chloride) this equates to approximately 1 1 /2 pounds of salt per minute of fill. 4. Click the UP or DOWN to switch between 1-99 days or 7 Day. Press SET HOUR 5. Press SET HOUR until you get back to Current Time.http://clackvalves.net/pdf/documents/... To Enter Days between Regen 1. From normal mode, press SET HOUR + UP buttons simultaneously for 3 seconds and release 2. Regeneration Time: Set the clock to the hour the regeneration should occur by using the UP or DOWN buttons. An arrow points to PM after 12. Press SET HOUR to go to STEP 3ID. 3. Days To Regen: Set the number of days between regenerations. The allowable range is 1 to 99. Press SET HOUR to exit Installer Displays & Settings. To Enter Settings for 7 day option 1. From normal mode, press SET HOUR + UP buttons simultaneously for 3 seconds and release. 2. Regeneration Time: Set the clock to the hour the regeneration should occur by using the UP or DOWN buttons. An arrow points to PM after 12. Press SET HOUR to go to STEP 3I7. 3. Current Day of Week: Set the current day of the week by using the UP or DOWN buttons (Sunday being d1). Press SET HOUR to go to STEP 4I7. 4. Sunday Regeneration: To regenerate on Sunday use the UP or DOWN button until the arrow points to Regen. If the arrow does not point to Regen a regeneration will not occur on Sunday. Continue for the other days of the week you want regeneration. Press SET HOUR Done. Go here for your next video on Clack water filtration and I’ll see you there!   • Clack WS1 Water S...   LOVE GARY THE WATER GUY AND WANT TO LEARN MORE ABOUT WATER FILTRATION FOR YOUR FAMILY? HERE ARE SOME NEXT STEPS! SUBSCRIBEhttps://www.youtube.com/c/garythewate... 2) LET’S CONNECT!https://www.facebook.com/WaterEstore/https://twitter.com/WaterEstorehttps://www.linkedin.com/company/the-...https://www.instagram.com/Water_Estore/https://www.instagram.com/WaterStoreM... 3) CONTACT! info@WaterEstore.com or info@WaterStoreMidland.com 4) SHOP! Midland www.WaterStoreMidland.com Canada www.WaterEstore.ca USA www.WaterEstore.com Please share this video   • How to SET TIME a...
